2027 Norco Storm 20
Overview
Frameset
FRAME: Aluminum, 9x135mm QR, 20"
FORK: SR Suntour XCT Coil w/ Soft Spring and Preload, 63mm, 9x100 QR
Drivetrain
REAR SHIFTER: Shimano SL-RV200-6R, 6sp, gripshift
REAR DERAILLEUR: Shimano TZ-500, 6sp, Direct mount
CRANKSET: Alloy 3pc, 140mm, 28T Narrow Wide
BOTTOM BRACKET: Sealed bearing, ST 68mm
CASSETTE: Shimano MF-TZ500-6, 14-28T, 6sp, Freewheel
CHAIN: KMC Z6
Brakes
FRONT BRAKE: Tektro Aries, resin pads, Mechanical Disc
FRONT BRAKE ROTOR: 6-Bolt, 160mm
REAR BRAKE: Tektro Aries 160mm, Mechanical Disc
REAR BRAKE ROTOR: 6-Bolt, 160mm
BRAKE LEVERS: Tektro Aries alloy Jr. levers w/ reach adjust
Components
HANDLEBAR: Alloy Jr. Riser, 540mm, 30mm rise
STEM: Alloy, 35mm length, 31.8mm clamp
SEATPOST: Norco Alloy, 27.2mm, 250mm length
HEADSET: External Cup Ball Bearing, 1-1/8" EC34
HEADSET SPACER: 1x10mm, 2x5mm
SADDLE: Norco Youth, steel rail
GRIPS: Norco Youth, 115mm length
PEDALS: Jr. MTB Flat, 9/16"
SEATPOST CLAMP: Norco Alloy bolted, 31.8mm ID
Wheels
FRONT HUB: Formula DC-1420, 9x100mm QR, 28h, 6-bolt
REAR HUB: Formula DC-31R-7S, 9x100mm QR, Freewheel, 28h, 6-bolt
RIMS: Aluminum DW, 28h, 20" MTB
FRONT TIRE: CY Trail, 20x2.25", Wire
REAR TIRE: CY Trail, 20x2.25", Wire
SPOKES/NIPPLES: Stainless Steel w/ Brass Nipples - Black
Weight
WEIGHT: 10.63 kg (23.4 lbs)
