DETAILS
Platform: SuperSix EVO SE
Model Name: SuperSix EVO SE 2
Model Code: C17272U
FRAMESET
Frame: SuperSix EVO CX Carbon, internal cable routing w/ Switchplate, 12x142mm Speed Release thru-axle, PF30-83 Ai, flat mount disc, integrated seatpost binder
Fork: SuperSix EVO CX Carbon, integrated crown race, 12x100mm Speed Release thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/2", 55mm offset
Headset: Integrated, 1-1/8" – 1.5"
DRIVETRAIN
Rear Derailleur: Shimano GRX 810, Shadow RD+
Front Derailleur: Shimano GRX 810, braze-on
Shifters: Shimano GRX 600, 11-speed
Chain: Shimano HG601, 11-speed
Crank: Cannondale 1, PF83a w/ SpideRing, 46/30
Rear Cogs: Shimano 105, 11-34, 11-speed
Bottom Bracket: Cannondale Alloy PressFit30
BRAKES
Brakes: Shimano GRX 400 hydraulic disc, 160/160mm RT70 rotors
Brake Levers: Shimano GRX 600 hydraulic disc
WHEELS
Rims: DT Swiss G540, 28h, 24mm IW, tubeless ready
Spokes: Stainless Steel, 14g
Tire Size: 40
Wheel Size: 700c
Hubs: (F) Formula CL-712, 12x100mm centerlock / (R) Formula RXC-400, 12x142mm centerlock, Ai offset
Tires: Vittoria Terreno Dry TNT, 700x40c, tubeless ready
Front Tire: Vittoria Terreno Dry TNT, 700x40c, tubeless ready
Rear Tire: Vittoria Terreno Dry TNT, 700x40c, tubeless ready
COMPONENTS
Handlebar: Cannondale 2, 6061 Alloy, Compact
Stem: Cannondale 2, 6061 Alloy, 31.8, 7°
Grips: Cannondale Bar Tape, 3.5mm
Saddle: Prologo Dimension AGX, STN
Seatpost: HollowGram 27 SL KNØT, Carbon, 2-bolt clamp, 330mm, 0mm offset (46cm), 15mm offset (51–58cm)
