Bigfoot 3 Hydro Fat Bike
Overview
Green: built with Tektro mechanical disc brakes and a rigid alloy seatpost (no dropper).
Balanced weight distribution for maximum traction and a powerful pedaling position keep the Bigfoot 3 charging forward all year. Featuring hydraulic disc brakes.
Frameset
Frame: Butted X6 Aluminum
Fork: 6061 Aluminum
Drivetrain
Rear Shifter: Shimano Deore SL-M5100
Rear Derailleur: Shimano Deore RD-M5100
Crankset: Samox Alloy, 30T, 170mm (S), 175mm (M, L, XL)
Bottom Bracket: External, BSA Threaded
Cassette: Sunrace CMX8, 11–51T, 11 Speed
Chain: KMC X11
Brakes
Front Brake: Tektro HD-M275 Hydraulic, Resin Pads
Front Rotor: Tektro, 180mm
Rear Brake: Tektro HD-M275 Hydraulic, Resin Pads
Rear Rotor: Tektro, 160mm
Brake Levers: Tektro HD-M275
Components
Handlebar: Butted 6061 Alloy, 760mm, 15mm Rise
Stem: Alloy, 50mm Length, 31.8mm Clamp
Seatpost: TranzX YSP18 Dropper, 31.6mm, 130mm (S, M), 150mm (L, XL)
Headset: Sealed Bearing, Tapered
Headset Spacers: 2 × 10mm, Black
Saddle: Norco XC
Grips: VP Lock-On
Pedals: VP Nylon Flat
Seatpost Clamp: Alloy QR
Wheels
Front Hub: Sealed Bearing, 15 × 150mm, 6 Bolt
Rear Hub: Sealed Bearing, 12 × 197mm, HG, 6 Bolt
Rims: Alloy TR, 27.5", 32H
Front Tire: Vee Snow Avalanche TLR, 4.5", Studdable
Rear Tire: Vee Snow Avalanche TLR, 4.5", Studdable
Front Axle: 150mm × 15mm Thru-Axle
Rear Axle: 197mm × 12mm Thru-Axle
Spokes/Nipples: Stainless 14g, Black
Sizing
Not sure of your size? Call 416.769.0606 or come by 2100 Bloor St W and we’ll size you up.
Delivery and pickup
Free local delivery on bikes within the GTA, free pickup at 2100 Bloor St W, and shipping anywhere in Canada. See the shipping page for details.
Returns
Questions about a return or exchange? Read the refund policy or call the shop.
