FRAMESET
Frame: Carbon All-Mountain, Aluminum CS, 150mm Travel, 27.5" and 29" options, UDH, Hangerless Interface Compatible, Ride Aligned™
Fork: RockShox Lyrik Ultimate, Charger 2 RC2, 160mm, 37mm Offset (27.5), 44mm Offset (29)
Rear Shock: RockShox Super Deluxe Ultimate DH, LINM Tune, Meg Neg Air Can, 185x52.5mm Trunnion
DRIVETRAIN
Rear Shifter: SRAM GX Eagle
Rear Derailleur: SRAM GX Eagle
Crankset: SRAM GX Eagle DUB, 34T (27.5), 32T (27.5 S), 32T (29), 170mm
Bottom Bracket: SRAM DUB PF92
Cassette: SRAM Eagle XG-1275, 10–52T
Chain: SRAM Eagle
Chain Guide: e*thirteen Vario Top Guide
BRAKES
Front Brake: SRAM Code RSC, 4-Piston, Metallic Pads
Front Rotor: SRAM CenterLine, 200mm
Rear Brake: SRAM Code RSC, 4-Piston, Metallic Pads
Rear Rotor: SRAM CenterLine, 180mm
Brake Levers: SRAM Code RSC
COMPONENTS
Handlebar: Deity Ridgeline, 800mm, 25mm Rise
Stem: Alloy, 40mm Length, 35mm Clamp
Seatpost: TranzX YS105, Adjustable Travel, 34.9mm
– 150mm (S)
– 170mm (M)
– 200mm (L, XL)
Headset: FSA #57 E Sealed Bearing, Tapered
Saddle: SDG Bel Air V3
Grips: DMR DeathGrip Soft
– Thin (S, M)
– Thick (L, XL)
Seatpost Clamp: Norco design alloy nutted clamp, 38.5mm
WHEELS
Front Hub: Race Face Trace, 15x110mm Boost, 6-Bolt
Rear Hub: Race Face Trace, 12x148mm Boost, XD, 6-Bolt
Rims: Stan’s Flow S2, 32H
Front Tire: Maxxis Assegai 2.5" 3C Maxx Terra / EXO+ / TR, Folding
Rear Tire: Maxxis Minion DHR II 2.4" WT 3C Maxx Terra / EXO+ / TR, Folding
Spokes / Nipples: DT Competition DB Stainless Black
Valves: Stan’s 35mm Tubeless Presta
Sealant: Stan’s, 200ml
